Aims Power 3000 Watt Pure Sine Inverter 100A Charger with 120/240V 30A & 50A Transfer

Description

The ETL listed to UL 458 standards AIMS 3000 watt pure sine inverter charger has surpassed the ETL requirements and includes a 2 year warranty. This inverter is a a combination of an inverter, battery charger and AC auto-transfer switch into one complete system with a peak DC and AC conversion efficiency of 92%. It is unique as the inverter will bypass 50 amps 120V or 240V and outputs 120, ideal for RVs, work trucks, food trucks and boats. It is packed with unique features and it is one of the most advanced inverter chargers on the market today. This inverter also features power factor corrected, sophisticated multi-stage charging and pure sine wave output with unprecedentedly high surge capability to meet demanding power needs of inductive loads without endangering the equipment.

The powerful battery charger  is capable of 12 volts at 100 amps, and with power factor corrected, it uses 20-30% less energy from AC input than a standard charger, avoiding nuisance breaker trips or generator overloads. In response to the increasing demand of more advance battery charging, this model is equipped with Battery Temperature Sensing for increased charging precision. The overloads capacity is 300% of continuous output for up to 20 seconds to reliably support tools and equipment longer.

The transformers have been consistently improved for years to achieve the best balance of conversion efficiency, idle consumption and minimum THD. The idle consumption of the line is ultra-low, roughly 1.5% of its rated power. The AC battery priority switch and auto generator start functionally making it ideal to work in either backup power or renewable energy applications.

In AC priority mode, when utility AC power cuts off, the transfer relay is de-energized and the load is automatically transferred to the inverter output. Once the qualified AC utility is restored, the relay is energized and the load is automatically transferred to AC utility.

When customized to battery priority mode via the DIP switch, the inverter will extract power from external power sources in renewable energy systems and a minimal cycle of the battery will be required. With the availability of the auto generator start, an electrical generator can be integrated into the system as a backup and started when the battery voltage goes low.

Features:

  • Listed to UL 458 Standards
  • Bypasses 50 amps 120V or 240V and outputs 120V
  • 2 year warranty
  • 3000 watt low frequency inverter
  • 9000 watt surge for 20 seconds -3x surge capability
  • Battery priority selector
  • AC direct connect terminal block
  • GFCI – 20 amps
  • Marine coated and protected
  • Multi stage smart charger 100 amps
  • Remote panel available
  • Auto gen start
  • Auto frequency
  • 10msec typical transfer time
  • 7 battery type settings for charger including lithium

Product Specifications

Aims Power 3000 Watt Pure Sine Inverter 100A Charger with 120/240V 30A & 50A Transfer Product Specifications

Specifications:

 OUTPUT Continuous Output Power 3000 Watts / 3KW
Surge Rating (20 secs) 9000 Watts / 9KW
Starting Electric Motor (HP) 3 HP
Output Waveform Pure Sine
Nominal Efficiency >92% (Peak)
Line Mode Efficiency >95%
Power Factor .9 – 1
Nominal Output Voltage (rms) 120Vac
Output Voltage Regulation ± 10% RMS
Output Frequency 50/60 Hz ±0.3Hz
Short Circuit Protection YES. Current Limit Function (fault after 1 sec)
Typical Transfer Time 10ms (MAX)
Max THD @ Full Linear Load <20%
DC INPUT Nominal Input Voltage 12 Vdc
Minimum Start Voltage 10Vdc
Low Battery Alarm 10.5Vdc / 11.Vdc
Low Battery Trip 10Vdc / 10.5Vdc
High Voltage Alarm & Fault 16Vdc
High DC Input Recovery 15.5Vdc
Low Battery Voltage Recover 13Vdc
Sleep Mode Threshold >50 Watts (Power Saven On)
CHARGE Input Voltage Range Narrow: 100-135Vac Wide: 90-135Vac
Input Frequency Range Narrow: 47-55 ±0.3Hz @ 50Hz, 57-65 ±0.3Hz @ 60Hz
Output Voltage Depends on battery type
Charger Breaker Rating (120 Vac) 30A
Max Charge Rate 100A
Over Charge Protection Shutdown 15.7V
Battery Type Fast Vdc        Float Vdc
Gel USA 14           13.7
AGM 1 14.1        13.4
AGM 2 14.6        13.7
Sealed Lead Acid 14.4        13.6
Gel Euro 14.4        13.8
Open Lead Acid 14.8        13.3
Lithium 14.4 (NOTE: INVERTER MAY SAY CALCIUM BUT CHARGING ALGORITHM BUILT INTO THE INVERTER IS FOR LITHIUM)
De-sulphation 15.5 for 4 hours
Battery Temp Sensor YES. Part # PICGLFBATS
BYPASS & PROTECTION Input Voltage Waveform Pure sine from grid or generator
Nominal Votage 120Vac
Low Voltage Trip 80V/100V ±4%
Low Voltage Re-engage 90V/100V ±4%
High Voltage Trip 140V ±4%
High Voltage Re-engage 135V ±4%
Max Input AC Voltage 150Vac
Nominal Input Frequency 50Hz or 60Hz (auto detect)
Low Freq Trip Narrow: 47 ±0.3Hz @ 50Hz, 57 ±0.3Hz @ 60Hz                                 Wide: 40 ±0.3Hz for 50/60Hz
Low Freq Re-engage Narrow: 48 ±0.3Hz @ 50Hz, 58 ±0.3Hz @ 60Hz                                  Wide: 45 ±0.3Hz for 50/60Hz
High Freq Trip Narrow: 55 ±0.3Hz @ 50Hz, 65 ±0.3Hz @ 60Hz                                  Wide: No limit for 50/60Hz
High Freq Re-engage Narrow: 54 ±0.3Hz @ 50Hz, 64 ±0.3Hz @ 60Hz                                 Wide: No limit for 50/60Hz
Output Short Cirucit Protection Circuit Breaker
Bypass Breaker Rating (120 Vac) 50A
Bypass Breaker Rating (240 Vac) 50A
GFCI Rating 20A
MECHANICAL Mounting Predrilled holes for wall/ground
Dimensions 16.25″L x 11″W x 7″H
Weight 59 lb
Shipping Dimensions 21″H x 14″W x 12″H
Shipping Weight 64 lb
Displays Status LEDs/Optional LCD Remote
Warranty 2 Year
