Humminbird XP 9 HW In-Hull Transducer [710275-1]

Humminbird Logo
Top Authorized Dealer
Manufacturer Warranty Included
SKU OGL-73640
Save 22% Save 22%
Original price $129.99
Original price $129.99 - Original price $129.99
Original price $129.99
Current price $101.99
$101.99 - $101.99
Current price $101.99
Availability:
Low stock

Get it between -

Profile Pic

Have a question? Talk to one of our trusted experts today!

Instant Live Chat: Chat IconChat Now

Call or Text us: Phone Icon 415-481-4075

Price Match Policy

Price Match

Here at OffGrid Living, we want to offer youĀ the bestĀ prices online.

If you happen to find a lower price for the same product, we will guarantee to match their price or beat their price. Note,Ā this does not apply to all products in the store. Please reach out to us via email or chat if you want a price match or price beat.

For the policy to apply, please send us a screenshot, link, or any other evidence of the product being priced lower than oursĀ before making the purchase.

Refer to our Price Match Policy Rules.

Refunds & Returns Policy

At OffGrid Living, we are proud to have the best refund and return policies in the industry. If you’re not satisfied with your purchase for any reason, you may return it to us within 30 days for a refund.

If you have a problem with our order (there are missing components, damages, or the product is not functioning), please reach out to us as quickly as possible. Some of the problems can be resolved by going through the product manual or the product FAQs.

Refer to our Refunds & Return Policy for more details.

Shipping & Delivery

Order Processing

Once we receive your order, we will send you a confirmation email. Then we will process the order by confirming that the product is in stock and ready for shipment. If any of the items in your order are back-ordered, we will reach to you via email or phone and you may choose to either wait or receive a 100% refund.

Please allow 1-3 days for processing your order.

Shipping

We ship to the lower 48 continental United States only at this time.

Shipping times and shipping method will depend on the specific product and brand you purchase. If you have any shipping question, feel free to ask on the chat or email us at info@offgridlivingsolutions.com.

We will send tracking information by email the same day the shipping tracking number is created/available.

Before you sign the shipping bill, please THOROUGHLY INSPECT YOUR ITEM. Signing for the receipt of a damaged product removes the liability of the shipping company and OffGrid Living. Once you accept your shipment as non-damage, your item is your property.

Delivery time

Shipping Timeline listed above is an estimate. Please call or message the web chat for precise ETAs.

Humminbird XP 9 HW In-Hull Transducer [710275-1]

In-Hull Dual Spectrum CHIRP Transducer supports Dual Spectrum CHIRP 2D Sonar with high frequency beam and wide cone angle, offering CHIRP range of 150-220kHz and max depth of 1200ft. Intended for glue-in installation inside single layer fiberglass hulls. Includes epoxy kit and 20’ cable.Ā

Features:

  • This accessory is compatible with the following Humminbird products: HELIX 5 CHIRP G2 – GPS-equipped models only, HELIX 7 CHIRP G2/G3 – GPS-equipped and CHIRP DI G2 models, HELIX 7 CHIRP G2N/G3N – All models, HELIX 8 CHIRP G3N – All models, HELIX 9 CHIRP G2N/G3N – All models, HELIX 10 CHIRP G2N/G3N – All models, HELIX 12 CHIRP G2N/G3N – All models, ICE HELIX CHIRP G2 – All models (In Open Water Mode).
  • Side Imagingā„¢ and Down Imagingā„¢ units can support the XP 9 HW as a 2D sonar only transducer. This transducer does not support Side Imaging or Down Imaging.
  • Dual Spectrum CHIRP Frequencies: Full: 150-220 kHz, Narrow: 180-240 kHz, Wide: 140-200 kHz
  • Dual Spectrum CHRIP Max Depth: 1200ft (365m)

WarningWARNING: This product can expose you to chemicals including LEAD which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Product Specifications

Humminbird XP 9 HW In-Hull Transducer [710275-1] Product Specifications

Specification Details
Model XP 9 HW
Product Code 710275-1
UPC 0082324053108
Mount Type In-Hull
Mounting Style In-Hull
Sonar Type Dual Spectrum CHIRP (2D Sonar)
Imaging Support Standard 2D (No Down or Side Imaging)
CHIRP Range High Wide
Temperature Sensor No
Speed Sensor No
Pins 7-pin connector
Cable Length 20 ft
Compatible Models HELIX 5, 7, 8, 9, 10, 12, 15; ICE HELIX
Box Dimensions 4" H Ɨ 8" W Ɨ 9" L
Box Weight 0.8 lbs
Warranty One-Year Warranty

Product Manual

Owner's Manual (pdf)

English Transducer Resource Guide

Accessory Resource Guide

Transducer Compatibility Guide

HELIX Start Up Notice - Special Instructions

Inside the Hull Mounted Transducer Installation Instructions

Product Warranty

Humminbird Warranty

The Humminbird warranty we offer is product-dependent. The warranty begins at the date of purchase. When requiring any service/repairs for your Humminbird product, you will need your original receipt of purchase for warranty coverage. If you do not have your receipt of purchase, we will reference your product's serial number and base your warranty coverage off the date of manufacture. We recommend that you write the serial number down somewhere outside of your boat to have it available for future reference.

Humminbird 2-Year Limited Warranty

This warranty covers the following products:

  • All XPLORE models
  • All APEX models
  • All SOLIX models
  • HELIX 8 / 9 / 10 / 12 / 15 models
  • ICE HELIX 9 models (with MEGA Live or MEGA 360 Imaging)
  • ICE Flasher models (ICE-55, ICE-45, and ICE-35)
  • MEGA Live 1 Imaging transducersĀ
  • MEGA Live 2 Imaging transducersĀ
  • MEGA 360 Imaging transducers

Download Humminbird 2-Year Limited Warranty Terms (PDF)

Humminbird 1-Year Limited Warranty

This warranty covers the following products:

  • HELIX 5 / 7 models
  • ICE HELIX 5 / 7 models
  • All accessories
  • All cartography products

Download Humminbird 1-Year Limited Warranty Terms (PDF)

Humminbird Cartography 1-Year Limited Warranty

This warranty covers the following products:

  • All cartography products including LakeMaster and CoastMaster charts

Download Humminbird Cartography 1-Year Limited Warranty Terms (PDF)
