LINIOTECH 15KVA Hybrid Inverter All in One solar Inverter | 15kW PV Input | 11.4kW AC Output

Description

GO GREEN! LOWER CARBON!

MAXIMIZE ENERGY INDEPENDENCE.

Power your home, business, or commercial facility with the Liniotech 15kPV Hybrid Inverter, engineered to deliver maximum energy efficiency, smart battery storage integration, and high-output solar conversion—all in one robust, scalable solution.

⚡️ Key Features of the Liniotech 15kPV ESS Hybrid Inverter

✅ Massive 15kW Solar Input with 3 MPPTs

  • Accepts up to 15,000W of PV input (200% oversizing supported)

  • Dual high-amperage (30A) MPPTs for optimal PV harvesting

  • Wide voltage range (90-540VDC) supports modern high-efficiency solar panels

✅ High AC Output and Expandability

  • 11.4kW continuous AC output, 20kW surge

  • Split-phase (120/240V) and 208V 3-phase compatible

  • Stack up to 9 units for 90kW output – perfect for commercial scalability

✅ Advanced Battery Integration

  • Supports 48V LiFePO4 or lead-acid batteries (40-64V range)

  • Up to 210A charge/discharge current

  • Seamless integration with battery brands like Liniotech, EG4, Pytes, BYD, Pylontech, simpliphi, fortress power, Discover AES and more

✅ Grid-Tied, Off-Grid, or Hybrid Use

  • <10ms transfer time for sensitive electronics

  • AC-coupling compatible – keep existing SolarEdge, Enphase, or microinverter systems and just add battery storage

  • Export limiting for compliance in utility-regulated zones

✅ Home Backup Ready

  • Generator-ready input for uninterrupted backup

  • Integrated Rapid Shutdown (RSD) and AFCI for NEC 2023 compliance

✅ Smart Energy Monitoring and App Control

  • Real-time data via Liniotech app or web portal

  • Remote firmware upgrades, diagnostics, and performance analytics

  • WiFi / LAN / RS485 / CAN interfaces for BMS, smart meters, and home automation


Versatile Use Cases

  • Residential Solar with Battery Backup

  • Commercial & Industrial Solar Systems

  • Off-Grid Cabins & Remote Locations

  • Whole-Home Energy Backup Systems

  • Farms, Restaurants, Schools, Hospitals, Museums


Advanced Features You’ll Love

  • 3 MPPTs for maximizing power harvest from multiple PV arrays

  • AC-coupling lets you retrofit battery storage into existing solar systems

  • Supports up to 30A input per MPPT—ideal for high-power solar modules

  • Integrated DC breakersanti-islandingsurge protection, and leakage detection

  • Flexible system modes: Self-ConsumptionTime-of-UseBattery PriorityGrid Sell

Compatibility:

Model LNT5K0228UL LNT6K0228UL LNT7K0228UL LNT10K0228UL
Efficiency
Max. Efficiency (PV to AC) 98.0%
Max. Efficiency (BAT to AC) 94.5%
Input (PV)
Max. PV Input Power 7,500W 9,000W 12,000W 15,000W
Max. PV Voltage 600V
Start-up Voltage 90V
MPPT Operating Voltage Range 70V-540V
Max. Input Current per MPPT 30A/22A 30A/22A/22A
Max short current per MPPT 40A/30A 40A/30A/30A
String per MPPT 4(2/2) 6(2/2/2)
Nos. of MPPT 2 3
Input / Output (BAT)
Battery Type Lithium-ion/Lead-acid
Nominal battery voltage 48V
Battery voltage range 40V-64V
Max. charge/discharge current 210A/130A 210A/130A 210A/180A 210A/210A
Max. charge/discharge power 10,000W/5,000W 10,000W/6,000W 10,000W/7,600W 11,400W/11,400W
Output (Grid)
Nominal AC Output Power 5,000W 6,000W 7,600W 10,000W
Max. AC Output Apparent power 5,500VA 6,600VA 7,600VA 11,400VA
Max. AC Output Power (PF=1) 5,500W 6,600W 7,600W 11,400W
Nominal AC Output Current 20.9A/24.1A 25A/28.9A 31.7A/36.6A 41.7A/47.5A
Max. AC output current 26.5A 31.8A 40.4A 47.5A
Nominal Grid Voltage 120/240V (Split phase) / 208V (2/3 phase)
Nominal Grid Frequency 50 Hz /60Hz
Grid Frequency Range 45Hz-55Hz/55Hz-65Hz((Adjustable)
Power Factor > 0.99 @rated power (Adjustable 0.8 LG – 0.8 LD)
THDI <3% (Rated Power)
Output (Back Up)
Nominal Output Power 5,000W 6,000W 7,600W 10,000W
Nominal Output Current 20.9A/24.1A 25A/28.9A 31.7A/36.6A 41.7A/47.5A
Peak Output Apparent Power(1s) 10,000VA 12,000VA 15,200VA 20,000VA
Nominal Output Voltage 120/240V (Split phase) / 208V (2/3 phase)
Nominal Output Frequency 50 Hz /60Hz
Transfer Time <10ms
THDV <3% @100% R Load
Protection
Protection Category Class I
DC Switch Yes
Anti-islanding Protection Yes
AC Overcurrent Protection Yes
DC/AC Overvoltage Protection DC Type II, AC Type III
AC Short Circuit Protection Yes
DC Reverse connection Yes
Surge Arrester DC Type II, AC Type II
Insulation Resistance Detection Yes
Leakage Current Protection Yes
AFCI Yes
RSD Yes (APsystems Sunspec)
Generator Yes
General
Max. Operation Altitude 2000m
Ingress Protection Degree IP65/NEMA 3R
Operating Temperature Range -25~60℃(>45℃ derating)
Relative Humidity 0~100%
Cooling Method Fan Cooling
Mounting Wall bracket
Dimensions (W*H*D) 16.5*31.5*9.4 inch(420mm*800mm*240mm)
Weight 40Kg/88Ib
PV Connection Way Terminals
HMI & COM
Display Wireless & APP + LED , LCD (optional)
Communication Interface RS485/CAN (for BMS), DRM/RS485 (for meter), RS485 , Optional: WiFi /LAN
Certification
Grid UL1741SB, IEEE1547: 2018, HECO SRD 2.0
Safety UL 1741/CSA C22.2/UL 1699B
EMC FCC Part 15 Class B
Warranty 10 Years

Product Specifications

LINIOTECH 15KVA Hybrid Inverter All in One solar Inverter | 15kW PV Input | 11.4kW AC Output Product Specifications

Feature Value
PV Input Max 15,000W, 600V, 3 MPPT (30A per MPPT)
Battery 48V Nominal, 210A Charge/Discharge, LiFePO4 or Lead-Acid
AC Output 11.4kW Peak, 120/240V Split Phase & 208V
Transfer Time <10ms
Parallel Units Up to 9 (90kW Max System)
Monitoring WiFi, App, RS485, CAN
Certifications UL1741SB, IEEE1547, HECO, FCC, UL1699B
Dimensions 16.5” x 31.5” x 9.4” – 88 lbs
Protection AFCI, RSD, Surge, Short Circuit, Over/Undervoltage

Product Manual

Liniotech Hybrid Inverter Owners Manual

Liniotech Brochure

Product Warranty

10 years of warranty!
