MRCOOL DIY® 5th Gen E Star 12,000 BTU Single Zone Mini Split Condenser 115V (DIY-12-HP-C-115D25-O)

Description

The 5th Generation 5th Generation MRCOOL® DIY® 12k BTU 23.5 SEER Ductless Heat Pump Single Zone Mini Split Condenser makes home climate control easier than ever. Designed for effortless installation, this system requires no special tools or professional experience and is ideal for spaces between 350-500 sq. ft. With a pre-charged 25-foot QuickConnect® line set filled with R-454B refrigerant, setup is simple and eliminates the need for vacuuming. The included DIYPRO® cable enhances durability, replacing traditional electrical conduit to protect against weather, animals, and yardwork damage. Controlling your comfort is seamless with multiple options, including the included remote, the SmartHVAC app for Apple and Android devices, or hands-free commands via Amazon Alexa and Google Assistant.

Additionally, the Gold Fin Condenser provides exceptional corrosion resistance, making it a great choice for coastal environments. Equipped with a variety of features, this system enhances efficiency and comfort. The Timer function helps manage energy use, while Auto mode maintains your desired temperature without constant adjustments. After a power outage, the system automatically resumes previous settings, and the anti-mildew function reduces condensation buildup in the air handler.

Built for longevity, the 5th Generation MRCOOL® DIY® Mini Split offers an industry-leading warranty, including a limited lifetime warranty, plus a 7-year compressor and 5-year parts warranty. Combining advanced technology, user-friendly operation, and long-term reliability, this system is designed for hassle-free home comfort.

Features

  • NEEP ccASHP Listed
  • Intertek listed 5031495
  • Easy DIY installation
  • Future-proof your investment with the included DIYPro® cable, eliminating the need for electrical conduit.
  • Keep the included remote close by, and MRCOOL DIY®'s Follow Me® function will track the air temperature around you to ensure maximum comfort.
  • The MRCOOL® Smart HVAC Controller® Module and App fully support Google Assistant & Amazon Alexa out of the box.

Product Specifications

MRCOOL DIY® 5th Gen E Star 12,000 BTU Single Zone Mini Split Condenser 115V (DIY-12-HP-C-115D25-O) Product Specifications

Dimensions

11.93" D x 21.85" H x 30.12" W

SEER2

23.5

EER2

12.5

HSPF2-4

10.2

HSPF2-5

7.6

Tonnage

1

Cooling Capacity (BTU)

12000

Heating Capacity (BTU)

12000

Voltage (V)

115

Phase

1

Cycle

60

Max Fuse Breaker (A)

20

Min Circuit Ampacity (A)

18

Color

White

Zone Capacity

1

Refrigerant Type

R-454B

Refrigerant Volume (Oz)

30.34

Decibel Rating (DBA)

54

Inverter

DC

Line Set Length

25

Max Lineset Length (FT)

82

Liquid Line Size

1/4

Suction Line Size

3/8

Compressor Motor Type

Rotary

Auxiliary Heater Included

No

Auxiliary Heater Available

No

Fan Only Option

Yes

Quiet Mode

Yes

Auto Cool

Yes

WIFI Compatibility

Yes

APP Compatibility

Yes

Works with IOS

Yes

Workw with Android

Yes

UL Listed

Yes

ETL Listed

Yes

Energy Star Certified

Yes

AHRI Certified

Yes

Registered Warranty

Extended Limited Lifetime*

Base Parts warranty

5

Base Compressor Warranty

7

Has Batteries

Yes

Contains Electronics

Yes

Contains Chemicals

Yes

Contains Aerosol

Yes

Contains Compressed Gas

Yes

Proposition 65 Warning

Yes

Net Weight (Lbs)

83.11

Gross Depth (In)

16.54

Gross Height (In)

27.56

Gross Width (In)

36.22

Gross Weight (Lbs)

65.48

Product Manual

Brochure
Installation Manual
Remote Manual
Warranty
Accessory Manual

Product Warranty

MRCOOL Limited Lifetime Warranty

MRCOOL distributor (hereinafter “Company”) warrants this product against failure due to defect in materials or workmanship under normal use and maintenance as follows.

All warranty periods begin on the date of original installation. If the date cannot be verified, the warranty period begins one hundred twenty (120) days from date of manufacture. If a part fails due to defect during the applicable warranty period Company will provide a new or remanufactured part, at Company’s option, to replace the failed defective part at no charge for the part.

This limited warranty is subject to all provisions, conditions, limitations and exclusions listed on the right side.

LIMITATIONS OF WARRANTIES

ALL IMPLIED WARRANTIES AND/OR CONDITIONS (INCLUDING IMPLIED WARRANTIES OR CONDITIONS OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR USE OR PURPOSE) ARE LIMITED TO THE DURATION OF THIS LIMITED WARRANTY, SOME STATES OR PROVINCES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY OR CONDITION LASTS, SO THE ABOVE MAY NOT APPLY TO YOU.

THE EXPRESS WARRANTIES MADE IN THIS WARRANTY ARE EXCLUSIVE AND MAY NOT BE ALTERED, ENLARGED, OR CHANGED BY ANY DISTRIBUTOR, DEALER, OR OTHER PERSON, WHAT SO EVER.

Product FAQs

Q1 How do I register my warranty?

Answer: Go to here to file your warranty.

Q2 How do I find the AHRI number of my unit?

Answer: You can find links to the AHRI certificates on the documentation page at mrcool.com/documentation.
